Product Detail

Lathe WM210V-G

Maximum drilling£º
32mm
Max tapping diamete£
M16
Max face milling£º
63mm
Spindle stroke£º
75mm
Spindle swing angle£
¡À90¡ã
Motor power£º
900W
Voltage/frequency£º
220(380)V/50Hz
Hotline£º
0566-2610878
access
Tmall official website
Consultation
Consultation
Collect
  • DETAILS
  • AVAILABLE SIZES

High Precision Exit Lathe WM210V-G

No need to adjust the belt, switching between high and low gear at will

Max Drilling Capacity: 32mm

Max Tapping Capacity: M16

Max Face Milling Capacity: 63mm

Spindle Stroke: 75mm

Spindle Tilt Left and Right: ¡À90¡ã

Motor Power: 900w

Voltage/Frequency: 220(380)V/50Hz

Width of Bed

100mm

Number of Metric Threads

10

Spindle Bore

21mm

Range of Metric Threads

0.5-3mm

Spindle Taper

MT3

Number of Imperial Threads

8

Number of Spindle Speeds

Variable

Range of Imperial Threads

8-44T.P.I

Range of Spindle Speeds

50-2500rpm

Range of Longitudinal Feed

0.1-0.2mm

Tool Post Type

4

Swing Over Bed

210mm

Max Compound Slide Travel

55mm

Swing Over Cross Slide

134mm

Max Carriage Slide Travel

75mm

Distance between centers

400mm

Tailstock Travel

60mm

Max Carriage Travel

366mm

Tailstock Travel

MT2





×î´ó×ê¿×Ö±¾¶£º32mm
×î´ó¹¥Ë¿Ö±¾¶£ºM16
×î´óÃæϳֱ¾¶£º63mm
Ö÷ÖáÐг̣º75mm
Ö÷Öá×óÓÒ°Ú¶¯½Ç¶È£º¡À90¡ã
µç»ú¹¦ÂÊ£º900W
µçѹ/ƵÂÊ£º220(380)V/50Hz
